180 kW Motor Power Vibro Compaction Piling with Electric Power Type for Up To 30 Meters Depth Foundation Strengthening

All Category

Hydraulic Vibroflot

Mrs. Tina Tian

tianss@bjvibro.com

008613581545619

Contact Now

180 kW Motor Power Vibro Compaction Piling with Electric Power Type for Up To 30 Meters Depth Foundation Strengthening

Brand Name:	BVEM
Model Number:	BJVE-426-180Kw
MOQ:	1 set
Packaging Details:	wooden case / wooden pallet
Payment Terms:	L/C,T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO,CE

Document:

After-sales Service Provided:

Engineers Available To Service Machinery Overseas

Condition:

Weight:

2320kg

Product Name:

BJVE-426-180Kw

Motor Power:

180 KW

Dimension(l*w*h):

3020mm,3300*650*650mm

Warranty:

1 Year Or 2000 Hours

Color:

Green

Application:

Compaction And Replacement

Temperture:

20℃-+50℃

Engine:

300KW/380V/50HZ

Power Type:

Electric

Power(w):

180kw

Max. Amplitude:

22 Mm

Max. Speed:

1450 R/min

Wing Span Width:

778MM

Rate Current:

356 A

Centrifugal Force:

280 KN

Supply Ability:

600 sets/year

Highlight:

180 kW Motor Power Vibro Compaction Piling

Electric Power Type Vibroflot Equipment

Up To 30 Meters Depth Bottom Feed Vibroflot

Product Description

Vibro Compaction Piling for Thermal Power Plant Foundations

Vibro Compaction Piling is an advanced soil improvement technology designed to enhance soil stability and load-bearing capacity through vibratory compaction. This innovative foundation treatment method reaches depths up to 30 meters, making it ideal for thermal power plant projects requiring robust foundation support.

Advanced Technology Features

Maximum Depth

Up to 30 meters

Outer Diameter

426 mm

Generator Power

200-600 KVA

Vibration Amplitude

14-28 mm

Technical Specifications

Product Name	Vibro Compaction Piling
Model Number	75kW-260kW
Rate Current	148-500 A
Soil Types	Sandy and Granular Soils
Construction Time	Rapid, Typically 1-2 Days Per 1000 Sqm
Condition	New

BVEM BJVE-426-180 Top Feed Vibroflot

The BVEM BJVE-426-180 Top Feed Vibroflot delivers exceptional performance for challenging ground conditions with its 180 KW power output. This advanced system dramatically reduces soil settlement and significantly increases soil bearing capacity through precise vibration technology.

Key Advantages: 1450 RPM rotation speed with inverter control for operational flexibility • Robust vibrator size (3300x650x650 mm) for durability • Suitable for both underwater and on-land applications

Customization & Ordering

Brand: BVEM
Place of Origin: China
Certification: ISO, CE
Minimum Order Quantity: 1 unit
Delivery Time: 15-30 days
Payment Terms: T/T, L/C

Technical Support & Services

On-site installation guidance
Comprehensive maintenance services
Professional troubleshooting assistance
Operator training programs
Spare parts supply and support

Also known as Vibratory Compaction Piling, Vibro-Compaction Piling, or Vibration-Compaction Piling, this technology provides a cost-effective and reliable solution for achieving strong foundations in thermal power plants and other critical infrastructure projects.
