Top Feed Vibroflot with High Centrifugal Force Adjustable Speed and Large Amplitude for Vibro Compaction

Brand Name: BVEM
Model Number: BJVE 426-180、BJVE 450-260
MOQ: 1 set
Packaging Details: wooden case
Payment Terms: L/C,T/T
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
CE、ISO
Document:
BVEM-Top Feed Vibroflot.pdf
Condition:
New
Weight:
2320kg,3280kg
Motor Power:
180 KW,260 KW
Dimension(l*w*h):
3020*676*440mm,3310*700*450mm
Warranty:
1 Year Or 2000 Hours (whatever Occurs First)
Color:
Green
Application:
Vibro Compaction、Vibro Replacement
Engine:
300Kw/400Kw
Power Type:
Electric
Max. Amplitude:
22 Mm,26 Mm
Max. Speed:
1450 R/min
Rated Current:
380A
Centrifugal Force:
280kN,440 KN
Supply Ability:
600 sets /years
Highlight:

High Centrifugal Force Top Feed Vibroflot

,

Adjustable Speed Vibroflotation Equipment

,

Large Amplitude Vibro Compaction Equipment

Product Description
Comparative Analysis of Vibroflotation Equipment Series 1
In the field of vibroflotation equipment, products of different technical types and models exhibit significant differences in performance parameters and application scenarios. This analysis compares four vibroflotation equipment models—BJVE-426-180 (conventional electric), BJVE-450-260 (conventional electric), BJVH-350-150 (hydraulic), and BJVEF-450-225 (electric variable-frequency)—to provide professional references for equipment selection decisions.
Main Parameter Comparison
Vibro Model Electric Normal
BJVE-426-180		 Electric Normal
BJVE-450-260		 Hydraulic
BJVH-350-150		 Electric Frequency Conversion
BJVEF-450-225
Diameter (mm) 426 450 350 450
Power (kW) 180 260 150 225
Speed (rpm) 1450 1450 2600-2900 1450-1740
Centrifugal Force (kN) 280 440 250-350 520
Max. Amplitude (mm) 22 26 11 20
Comparison of Core Parameters: From Specifications to Power Performance
1. Differences in Basic Specifications
Diameter: The diameters of the four models vary significantly, ranging from 350mm (BJVH-350-150) to 450mm (BJVE-450-260 and BJVEF-450-225), with the BJVE-426-180 measuring 426mm. Diameter directly affects the equipment's adaptability to the operating environment. Larger-diameter equipment offers a wider deep vibration influence range and compaction scope, while smaller-diameter models provide stronger penetration, greater flexibility, and produce smaller pile diameters.
Power: Power ranges from 150kW (BJVH-350-150) to 260kW (BJVE-450-260). The electric variable-frequency model BJVEF-450-225 has a power of 225kW, and the conventional electric model BJVE-426-180 has 180kW. Power determines the equipment's vibration output capacity and continuous operating intensity.
2. Power and Vibration Performance
Speed: Conventional electric models BJVE-426-180 and BJVE-450-260 have a fixed speed of 1450rpm, classified as constant-speed vibroflotation equipment. They are mostly used in common soft soil foundation treatment projects.
The electric variable-frequency model BJVEF-450-225 features adjustable speed (1450-1740rpm), allowing flexible adjustment of vibration frequency according to operational needs. It is suitable for soft foundations with shallow hard soil layers.
The hydraulic model BJVH-350-150 has a wide speed range (2600-2900rpm). Its high speed enables faster vibration frequency, making it suitable for complex hard soil layers.
Centrifugal Force: Centrifugal force is the core embodiment of the equipment's "exciting force". The BJVEF-450-225 leads significantly with 520kN, followed by the BJVE-450-260 (440kN), the BJVH-350-150 (250-350kN range), and the BJVE-426-180 (280kN). High centrifugal force means the equipment can more efficiently handle high-resistance, high-load vibration operations (such as deep foundation compaction and penetration capacity in hardness soil layer).
Maximum Amplitude: Amplitude determines the "influence width" of vibration. The BJVE-450-260 has the largest amplitude at 26mm, followed by the BJVE-426-180 (22mm), the electric variable-frequency model BJVEF-450-225 (20mm), and the hydraulic model BJVH-350-150 (only 11mm). Equipment with large amplitude provides a larger radius of influence on soil compaction around the vibration area during foundation compaction construction.
Tags:

vibro bottom stone column pile device

under water piling equipment

High Centrifugal Force Top Feed Vibroflot
