Hydraulic Vibroflot
>
Hydraulic Vibroflot with 150Kw Power and High Compaction Efficiency for Soil Improvement ISO 9001 Certified

Hydraulic Vibroflot with 150Kw Power and High Compaction Efficiency for Soil Improvement ISO 9001 Certified

Brand Name: BVEM
Model Number: BJVH-350-150
MOQ: 1
Price: 35000 $
Packaging Details: Wooden Case
Payment Terms: L/C,T/T
Detail Information
Place of Origin:
China
Certification:
CE、ISO 9001:2000、ISO 9001:2008
Vibrator Power:
150kW
Remote Control:
Yes
Vibroflot Weight:
1700 Kg
Outer Diameter:
350 Mm
Rotational Speed:
0-2900 Rpm
Air Compressor:
20 M³/min
Power Pack:
176 KW
Vibrator Length:
2250 Mm
Centrifugal Force:
214 KN
Driving Dia:
500-800 Mm
Warranty:
Either 1 Year Or 2000 Hours, Whichever Comes First
Supply Ability:
600set/Year
Highlight:

Hydraulic Vibroflot 150Kw power

,

Hydraulic Vibroflot high compaction efficiency

,

Hydraulic Vibroflot ISO 9001 certified

Product Description
Hydraulic Vibroflot with 150Kw Power and High Compaction Efficiency for Soil Improvement ISO 9001 Certified
Product Overview

With over 50 years of dedication to the vibroflotation industry, BVEM has focused on R&D and investment in vibroflotation products. Our BJVH-350-150 hydraulic vibroflot represents the culmination of technical expertise and innovation, delivering high-efficiency, stable performance for demanding vibroflotation projects.

Working Principle

This hydraulic vibroflot efficiently converts hydraulic energy into mechanical energy (rotational motion) through a hydraulic motor, driving the eccentric block to generate strong horizontal excitation force. Key advantages include:

  • Large output torque for demanding applications
  • Wide speed regulation range with stepless control
  • Excellent impact load resistance
  • Stable power output for consistent performance
Key Features
  • 0-2900rpm stepless speed regulation: Flexible operation matching various construction requirements and soil conditions
  • Wide stratum compatibility: Optimized design provides strong penetration in both soft soil and gravel-containing strata
  • Continuous high-power output: Ensures stable operation and improved project efficiency
  • Water-cooled motor not required: Enables dry method environmental protection construction
  • High adaptability: Compatible with various equipment including pump stations, rotary drilling rigs, excavators, and pile frames
CE Certified ISO 9001 Made in China
Applications

The BVEM Hydraulic Vibroflot (Model: BJVH-350-150) is designed for soil improvement across multiple construction scenarios:

  • Foundation Construction: Compacts soil to ensure stable building foundations
  • Road and Highway Projects: Enhances soil strength and reduces settling for durable infrastructure
  • Retaining Wall Installation: Improves soil stability and prevents erosion
Technical Evolution

BVEM has pioneered advancements in vibroflot technology, including:

  • Transition from electric to hydraulic driving systems
  • Development of both orifice filling and bottom discharge models
  • Expansion of mounting scenarios for diverse construction needs

This equipment provides contractors and engineers with a reliable, high-performance solution for soil improvement projects, combining quality construction with operational efficiency.
