| Brand Name: | BVEM |
| Model Number: | BJV130E-377 |
| MOQ: | 1 |
| Price: | Negotiable |
| Packaging Details: | wooden case |
| Payment Terms: | L/C, T/T, MoneyGram |
China top feed vibroflot equipment professional manufacturer BJV130E-377 device pile driver device for soft ground improvement
| BVEM Top Feed Vibroflot Spec. | ||||
| Type | BJV130E-377 | BJV130E-426 | BJV150E-426 | BJV180E-426 |
| Power/kW | 130 | 130 | 150 | 180 |
| Rotation speed/rpm | 1450-1800 | 1450 | 1450 | 1450 |
| Amplitude (at Tip)/mm | 19 | 17.2 | 18.9 | 18.9 |
| Centrifugal force/kN | 180-276 | 208 | 276 | 276 |
| Weight /kg | 1900 | 2320 | 2516 | 2586 |
| Diameter/mm | 377 | 426 | 426 | 426 |
| Length/mm | 3355 | 2963 | 3023 | 3100 |
| Diameter of the work pile/mm | (800-1200) | (800-1200) | (800-1200) | (1000-1500) |
Since our international trading department established in 2017, our vibroflotation equipment are favored by ground improvement construction team in Middle East. Big power vibroflot device have a good performance in medium sand soil. The effect range of vibrate density to soil in piles more than 4m, the soil relative density rate after treating can achieve more than 70%. (parts soil can achieve 95%.)
So far, our company has sold nearly 100 sets of equipment in the Middle East, especially in Saudi Arabia and Dubai.
On October 8-10, 2022, our team visited the construction site in Abu Dhabi, United Arab Emirates. Nearly ten sets of 180kW equipment produced by our company are working in order, which has been unanimously recognized by customers.
Application |vibroflotation (VF)
Vibroflotation VF gives good results in non-cohesive soils, sands, gravels and loose all in one aggregates. With a good result it is used also in non-cohesive mining waste, etc., containing not more than 5% fines: silt and clay. Soils containing more than 10% silt and clay fractions are not suitable for this compacting method. Vibroflotation VF is often used to dense thick embankment surfaces, molded by silting in, in areas flooded by water – by infilling.
The profile of China vibroflot supplier- Beijing vibroflotation engineer machinery co.,ltd (BVEM)
With 30 years experience of vibroflotation industry, BVEM researched and developed a variety of electric vibroflots motor power from 30 kw to 260 kw. BVEM’s vibroflots has complete specification model which makes widely using of range. The quality of the equipment and performance have already achieved the domestic industry leading level. Through the application of hundreds of domestic and international projects, including the Yangtze River Three Gorges Soft Ground Treatment Project, The Hong kong-Zhuhai-Macao Bridge Project, Dubai Palm Island Project,etc, BVEM has developed to be Asia's larger electrical vibroflots equipment manufacturers, and are being highly recognized by domestic and international clients.
Whole Process Sales Service BVEM provides
Geological Analysis
Giving the suggestion of feasible solution of foundation treatment.
Vibroflotation Design
Formulation of vibroflotation design scheme,quality control method and testing method.
Equipment Selection
Recommendation of vibroflots model.
Construction Scheme
Formulation of the feasible construction organization scheme.
Installation&Commissioning
Guiding the installation and commissioning of equipment.
Construction Guiding
Demonstration and training for the operation of vibroflotation.
|
|
