| Brand Name: | BVEM |
| Model Number: | BJV100E-377 |
| MOQ: | 1 |
| Price: | Negotiable |
| Packaging Details: | wooden case |
| Payment Terms: | L/C, T/T, MoneyGram |
100kW vibroflotation device for vibro compaction improving foundation liquefaction resistance
| Vibroflot Spec. | ||
| Type | BJV100E-377 | BJV100E-426 |
| Power/kW | 100 | 100 |
| Rotation speed/rpm | 1450-1800 | 1450 |
| Amplitude (at Tip)/mm | 19 | 17.2 |
| Centrifugal force/kN | 180 | 208 |
| Weight /kg | 1880 | 2073 |
| Diameter/mm | 377 | 426 |
| Length/mm | 3215 | 2883 |
| Diameter of the work pile/mm | (700-1200) | (800-1200) |
Vibroflotation techniques
Vibro compaction
Under the effect of vibration, the saturated sand soil liquefaction happen,which make the sand particles re-arranged and the soil interspace reduced.
Boring
By vibration and the flushing of water and/or air, the vibroflot penetrates to the designed depth.
Compaction
Compact the soil section by section up to the gound according to the requirements of the compaction current, compaction time and sectional compaction length.
Vibro replacement
Jet water and vibrate by vibroflot to form holes. Fill in pile holes by section with solid filling materials such as gravel (cobble) etc., to finally form composited foundation.
Boring
By vibration and the flushing of water and/or air, the vibroflot penetrates to the designed depth.
Backfill
Fill stones into the bore-hole, and compact section by section up to the ground according to the requirements of compaction current and the sectional compaction length.
BVEM· The top-level researcher of Vibrator in China
As the leader of vibroflotation industry in China, BVEM focus on vibroflotation market and formed a business platform with vibroflotation technique as core, on which there are three main business including the manufacturing and integration of VIBRIFLOTATION equipment, sales and service for vibroflotation equipment and foundation improvement construction undertaking.
BVEM is the largest manufacturer of electrical vibroflot in Asia and one of the authors of Chinese vibroflot manufacturing code.
As the active pusher of vibroflotation and the professional supplier of vibroflot, BVEM has developed vibroflotation application and supplied vibroflot equipment to 33 countries all over the world.With the enterprise mission of "OUTPERFORM to SERVE VIBRIFLOTATION", BVEM product was widespread in more and more countries with excellent reputation which came from the high recognition of high performance product and the top level whole process service.
|
|
