| Brand Name: | BVEM |
| Model Number: | BJV130E-426 |
| MOQ: | 1 |
| Price: | Negotiable |
| Packaging Details: | WOODEN CASE |
| Payment Terms: | L/C, T/T |
Economic and qualified electrical vibroflot used for vibro pile foundation BJV130E0 - 426
| Vibroflot Spec. | ||||
| Type | BJV130E-377 | BJV180E-377 | BJV130E-426 | BJV180E-426 |
| Power/kW | 130 | 180 | 130 | 180 |
| Rotation speed/rpm | 1450-1800 | 1450-1800 | 1450 | 1450 |
| Amplitude (at Tip)/mm | 19 | 21 | 17.2 | 18.9 |
| Centrifugal force/kN | 180-276 | 180-276 | 208 | 276 |
| Weight /kg | 1900 | 2140 | 2320 | 2586 |
| Diameter/mm | 377 | 377 | 426 | 426 |
| Length/mm | 3355 | 3485 | 2963 | 3100 |
| Diameter of the work pile/mm | (800-1200) | (1000-1200) | (800-1200) | (1000-1500) |
Vibroflot profile(BVEM)
BVEM is the largest manufacturer of electrical vibroflot in Asia and one of the authors of Chinese vibroflot manufacturing code.
As the active pusher of vibroflotation and the professional supplier of vibroflot, BVEM has developed vibroflotation application and supplied vibroflot equipment to 33 countries all over the world.With the enterprise mission of "OUTPERFORM to SERVE VIBRIFLOTATION", BVEM product was widespread in more and more countries with excellent reputation which came from the high recognition of high performance product and the top level whole process service.
Vibroflot characteristics
The vibroflot barrel and the motor housing are made of high strength forged steel
The motor coil adopts high temperature aging film envelop, long service life and good insulation effect
Unique circulating water cooled motor structure, good heat dissipation with high efficiency
Both vibroflot and motor are imported with FAG original bearing
Double-deck vibrating head design with good resistance, easy to replace
Unique bearing oil lubrication, further improve bearing life
|
|
