| Brand Name: | BVEM |
| Model Number: | BJV130E-426 |
| MOQ: | 1 |
| Price: | Negotiable |
| Packaging Details: | WOODEN CASE |
| Payment Terms: | L/C, T/T |
BVEM 426mm 130kw Vibro compaction piling machine foundation treatment soil improvement
| The Top Feed Electric Vibroflot Spec. | ||||||||
| Type | Power (kW) |
Rated current(A) | Max rotation speed(rpm) | Max amplitude (mm) |
Vibration power(kN) | Weight (kg) | Outer diameter(mm) | Length(mm) |
| BJV130E-426 | 130 | 255 | 1450 | 19 | 195 | 2250 | 426 | 2965 |
Vibroflot manufacturer profile (BVEM)
Comprehensive vibroflotation service
Vibroflotation VF gives good results in non-cohesive soils, sands, gravels and loose all in one aggregates. With a good result it is used also in non-cohesive mining waste, etc., containing not more than 5% fines: silt and clay. Soils containing more than 10% silt and clay fractions are not suitable for this compacting method. Vibroflotation VF is often used to dense thick embankment surfaces, molded by silting in, in areas flooded by water – by infilling.
Typical vibroflotation project cases by vibroflot from BVEM
1. Chinese first vibrator 30kW applied in Beijing Guanting resevior Dam foundation reinforcement
2. 75kW vibrator applied in Three Gorges cofferdam
3. 180kW vibro applied in the thrid runway of HongKong airport
4. 260kW applied in many Islands in UAE and KSA
5. 225kW inverter vibrator applied in Hydropower Station in Sichuan
6. Also in other Hydropower station project, 220kW vibrator drive pile depth of 71.63 meter
7. Bottom feed vibrator applied in Hong Kong Zhuhai Macao Bridge Hong Kong Port
8. Barge type bottom feed vibrator applid in Dila Bay port in Timor Leste
|
