| Brand Name: | BVEM |
| Model Number: | BJV260E-450 |
| MOQ: | 1 |
| Price: | negotiation |
| Packaging Details: | wooden case |
| Payment Terms: | L/C, T/T |
Vibro compaction to imprve soil bearing capacity by vibroflot equipment with 260KW motor
| The Top Feed Electric Vibroflot Spec. | ||||||||
| Type | Power (kW) |
Rated current(A) | Max rotation speed(rpm) | Max amplitude (mm) |
Vibration power(kN) | Weight (kg) | Outer diameter(mm) | Length(mm) |
| BJV260E-450 | 260 | 500 | 1450 | 25 | 520 | 3280 | 450 | 3400 |
China vibroflot supplier
BVEM (Beijing vibroflotation engineer machinery co.,ltd) focus on vibroflotation market and formed a business platform with vibroflotation technique as core, on which there are three main business including the manufacturing and integration of vibroflotation equipment, sales and service for vibroflotation equipment and foundation improvement construction undertaking. BVEM is the largest manufacturer of electrical vibroflot in Asia and one of the authors of Chinese vibroflot manufacturing code.
As a representative enterprise of vibroflotation industry, BVEM has nearly 30 national invention patents and utility model patents.As the chief editor, BVEM participated in the formulation of various industry standards. Successively won honor such as: High and New Technology Enterprise of Beijing city, AA Grade Credit Enterprise of Beijing city. Today BVEM has already grown up to be the benchmark and leading brand of the domestic vibroflotation industry.
1.The first one who introduced and studied vibro compact method in China
2.The first one who developed application in Chinese projects
3.Has the top experts of vibroflotation tech. and experienced construction management team
4.China first one who reserched and produced vibrators
5.China first and only one who produced the Bottom Feed Vibroflot
6.The first one who produced domestic hydraulic-driven vibrator
7.All types&models coverage:30kw-260kw
8.Editor-in-cheif of industry standards <Technical Specification of Vibroflotation Method in Hydrauelectric and Water Resources Projects>(DL/T5214-2005)
9.Editor-in chelf of industry standrds <Electrical Deep Vibrator>(DL/T 1557-2016)
10.China first one who developed vibroflotation application in variety of industry(thermal power,hydraulic power, petrochemical, highway,rail, port etc.)
11.Cooperate with DI and support to formulate the design and construction scheme
Vibroflotation
vibroflotation is one of a typical technique which is a widely used application for foundation soil improvement. In vibroflotation construction, vibroflot equipment makes a joint action of horizontal vibration and high pressure water or air shock to compact the loose sand layer or formed in soft soil of gravel column to compose the composite foundation with original soil together, finally achieve the improvement of soil by load capacity, settlement controlling as well as the anti-seismic capacity. Vibroflotation is often used in foundation treatment of dams, oil fields, power plants, ports, airports, bridges, etc.
|
|
